7 Troubleshooting VJ-1624/1624W OPERATION MANUAL
7-16
3. Move Print head section from the top of the media to the right.
NOTE
• When the head height is set to Low, change it to High and then shift Head.
After shifting Head, change the setting back to Low.
4.2.5.2 When setting the head height to High
4.2.5.3 When setting the head height to Low
4. Raise Media loading lever.
No. Name
1 Print head section
2 Roll media
No. Name
1 Media loading lever
2
1
1
To Next Page
