MUTOH ValueJet VJ-1624 - Page 73

VJ-1624/1624W OPERATION MANUAL 3 Before using
3-37
1. Loosen Fixing levers on the Roll media holders (both left and right) on the back of the printer. Set
the distance between Roll media holders wider than the actual width of the roll media to be set.
No. Name
1 Roll media holder (Left)
2 Roll media holder (Right)
3 Roll media
4 Fixing lever
13
4
1
2
24
