VJ-1624/1624W OPERATION MANUAL 3 Before using
3-47
b. After moving the roll media, fix it with Fixing levers of the right and left Roll media holders.
NOTE
• When tightening Fixing lever, press Roll media holder toward the printer. If you do not press
Roll media holder, Fixing lever may not be completely locked because of the weight of the roll
media.
8. Lower Media loading lever.
No. Name
1 Roll media holder (Left)
2 Roll media holder (Right)
3 Roll media
4 Fixing lever
No. Name
1 Media loading lever
2
3
31 2
1
3
4
4
1
To Next Page
