5-92 Chapter 5: Programming
Terminal Coupon Interface Parameters
Certainparametersmustbesettopermittheunittotransmitcoupondatatothehost
terminal.Theseareinadditiontothegeneralparametersthatarerequiredforother
scannerfunctions.
Note: SelectionofoptionalAdd‐Onbarcodesmayrequireadditionalprogramming.
TosettheCouponInterfaceParameters,perform
aseriesofstepsinadesignated
order.First,settheTerminalCouponSelect1parameters,andthensettheTerminal
CouponSelect2parameters.Selectoneoftheparametersbelowtodisplaythe
procedure.
Terminal Coupon Select 1
1. ScantheProgramModetag.
2.
ScantheHex3andHex8tagstoselectthisparameter.
3.
ScanaHex0throughHexFtagtosetaCouponSelect1parameter.
Coupon Select 1 Parameter Disable Enable
CouponwithP5optional Hex0 Hex1
Couponwith128Add–Onoptional Hex2 Hex3
Couponwith128Add–Onmandatory Hex4 Hex5
4. ScantheSaveandResettagtosavetheprogram(required).
Note: Repeatsteps1through4tosetthesecondCouponSelect1parameter.
Suggested Programming Sequence
•
ProgramMode
•
Hex3andHex8
•
Hex1
•
SaveandReset
•
ProgramMode
•
Hex3andHex8
•
Hex3
ScanProgramMode,Hex1,Hex7,HexF,Hex0,andSaveandResettagsto
completetheprogrammingfunction.
Note: ScanningtheDefaulttagresetsalloptions.
