Confidential and proprietary information of NCRCorporation.
Unauthorized use, reproduction and/or distribution is strictly prohibited.
12
Serial Ports 81
DB-9 Serial (Standard UART) 82
RJ50 Serial (Enhanced UART) 83
RJ12 Serial (Two Enhanced UART and Two Standard UART) 84
RJ45 Serial (One Enhanced UART and One Standard UART) 85
Operator Controls 86
Power Switch 86
Image Recovery Button 87
Trusted Platform Module (TPM) 88
Imager 89
Programming the Imager 89
Keypad 90
Keypad/Keyboard Remap Utility 90
Label Locations 91
CX7 15” 4:3 Display with Base 91
CX7 15.6” 16:9 or 18.5” Display with Base 92
CX7 15” 4:3 or 15.6” 16:9 or 18.5” Display with Integrated I/O 93
CX7 15” 4:3 Display with Remote I/O 94
CX7 15.6” 16:9 or 18.5” Display with Remote I/O 95
Hardware Installation 96
Installation Restrictions 96
Ergonomic Workplace 96
Installing the Terminal 97
Connecting ACPower 98
