Confidential and proprietary information of NCRCorporation.
Unauthorized use, reproduction and/or distribution is strictly prohibited.
51
Mounting Configurations
In addition to the integration of the board in the base, each I/O can be configured for a
wall mount solution, pole mount solution, or ordered in a remote chassis to permit
placement under the counter.
l
Table Top Stand below
l
Remote I/OChassis Pole Mount on page53
l
Integrated I/OChassis Stand/Wall/Pole Mount on page54
Table Top Stand
Table Top Stand with Remote Power Supply
The Power Supply is not integrated in the Base.
For CX7 15.6” 16:9 or 18.5” Display
l
with USBCentric I/O (Retail) (F033)
l
with Serial Centric I/O (Hospitality) (F035)
For CX7 15” 4:3 Display
l
with USBCentric I/O (Retail) (F043)
l
with Serial Centric I/O (Hospitality) (F045)
