PowerIn
Both USBCentric and Serial Centric I/O Boards accept +24V DC voltage input from an
external power supply. The Power In connector is a 4-pin DIN - CUI PD-40S or equivalent.
Pin Signal Name
1 GND
2 24V
3 GND
4 24V
