Connecting to a Network
Most business configurations require the terminal to connect to a network. Connecting to a
network enables communicating with other systems and devices also on the network.
Depending on business configurations, connecting to a network may allow connection to
the Internet.
CX7 with Base or Remote I/O
To connect the CX7 terminal with a Base or Remote I/O to a network, follow these steps:
1.
Connect the 10/100/1000 Ethernet Cable to the port labeled LAN In on the
I/Opanel. For more information, refer to I/O Ports on page61.
2. Connect the other end of the 10/100/1000 Ethernet Cable to the network hub.
Note
Consult with your business Information Technology (IT) representative to
determine the available connection, and to locate the network hub.
3.
Connect the Flat Ethernet Cable to the port labeled LANOut on the I/Opanel. For
more information, refer to I/O Ports on page61.
4.
Connect the other end of the Flat Ethernet Cable to the port labeled LANon the
CXHead. For more information, refer to CXHead Ports on page56.
