LAN

The Motherboard provides 10/100/Gb LAN support using Intel I219 “Jacksonville”.

Signal Name Pin Pin Signal Name

MDIP0 1 2 MDIN0

MDIP1 3 4 MDIN1

MDIP2 5 6 MDIN2

MDIP3 7 8 MDIN3

The LAN connector features Activity, Link, and Speed indicator LEDs. For more

information, refer to LAN Diagnostic LEDs on page124.
