NEC DS1000 - Page 113

DS1000/2000 Correspondence Course
DS2000 System Installation
NEC America DS1000/2000 Workbook ◆ 113
Connecting the 2-OPX Module
80000 - 41
BLK YEL
GRN RED
To digital
station
circuit on
DSTU PCB
25 Pair
Installation Cable
Station
Block
Cross
Connect
Block
14 AWG to known
Earth Ground
8-Pin
Connector
BLU-WHTWHT-BLU
625
Modular
Jack
One-Pair Cross-Connect
2-OPX Modular
DS1
F
G
