4-Slot Cabinet (P/N 80000)
● Four (4) Universal Slots
● A typical system configuration is
16 lines x 32 extensions (line and exten-
sion maximums are limited by load fac-
tor and slot availability)
● Wall mountable
● On/Off switch
● Installer-friendly design
● Minimum space requirement
● Light in weight
4-Slot Cabinet Default Setup with U-Slot Software and
CPU P/N 80025
A
Power Supply
CPU
16DSTU (300-315)
80000 - 58
P/N 80005/A
P/N 80025A
P/N 80021/A
Default Configuration:
0 trunks x 16 extensions
