DS1000/2000 Correspondence Course
DS2000 System Installation
NEC America DS1000/2000 Workbook ◆ 77
DS2000 System Installation
DS2000 Installation
❏
Determine a proper installation site.
Choose a central location for the cabinet that gives you enough room to install the
equipment and work comfortably. The installation layouts shown below will give
you a general idea how much room you’ll need, depending on your system.
80000 - 15A
Plywood backboard
Dedicated
AC Outlet
Surge
Protector
To earth
ground
To telco
ground
Station
Blocks
Station
Blocks
Trunk
Blocks
4’
4’
DS2000 4-Slot Cabinet Installation Layout
