DS1000/2000 Correspondence Course
System Programming
166 ◆ DS1000/2000 Workbook NEC America
Programming Guide
Step-by-step guide for setting up Voice Mail
(Sheet 1 of 4)
Step 1: Make sure you have analog ports reserved for Voice Mail.
• If you are using a 2-OPX Module, be sure to enter
type 21 in Program 1801 Extension Circuit Type.
The 2-OPX Module must be P/N 92177A.
• If you are using ports on an ASTU PCB, be sure
to enter type 15 in Program 1801 Extension Cir-
cuit Type.
• Following the instructions in your Voice Mail
documentation, connect the analog ports to Voice
Mail system.
Step 2: Assign a UCD Hunt Group for Voice Mail.
• Program 0510 - Group Number, select an avail-
able UCD Hunt Group for Voice Mail.
• In Program 0510 - Group Number, assign a mas-
ter number to the hunt group you designate for
Voice Mail.
Step 3: Enable Voice Mail programming.
• In Program 0201 - Voice Mail Installed, enter Y.
(Entering N enables Message Waiting.) You must
assign a Hunt Group Master Number in the pre-
vious step before programming this option.
• In Program 0201 - Voice Mail Extension Number,
enter the Voice Mail master extension number
(e.g., 700).
Step 4: Set up the Voice Mail ports.
• In Program 1802 - Voice Mail Port, enter Y for
each analog extension connected to Voice Mail.
• In Program 1807 - Hunt Type, enter hunt type 05
(for UCD hunting) for each analog extension con-
nected to Voice Mail.
• In Program 1807 - Hunt Master Number, enter
the Voice Mail UCD Group master number
(assigned in step 2 above) for each analog exten-
sion connected to Voice Mail.
To Next Page
