DS1000/2000 Correspondence Course
DS2000 System Installation
NEC America DS1000/2000 Workbook ◆ 117
7. When you are done entering the name, press HOLD.
You see the name and date of the first database stored. If no data-
bases are stored, you see:
9906: DB00 (empty)
8. The system assigns the name you entered in step 7 to the address you
select below:
- Press VOL ▲ or VOL ▼ to scroll through the addresses.
U Slot software 02.00.01 and above have 16 database addresses:
DB 00 to DB 15
OR
- Skip this step to select the currently displayed database.
9. Press HOLD.
Normally, you see
9906: SAVING . . . . . . . . .
The PC Card Active LED is on during backup.
If the address you choose already has data stored in it, you see:
REPLACE DB nn Y/N.
- Press N + HOLD to back up to step 5.
- Press Y + HOLD to proceed.
You automatically exit programming when the upload completes.
Keys for Entering Names
Press this
key:
Then one of these keys to enter the character in the white cell:
1 2 3 4 #
1&
-
(dash)
1
/
(backslash)
1
‘
(apostrophe)
1
1
2ABC 2
3DEF 3
4GH I 4
5JKL 5
6MNO 6
7PQRS7
8TUV 8
9WXYZ9
0SPACE: 0
* *
#
To enter characters in lower case (e.g.,
e
instead of
E
), press
MW
before pressing the key in the
first shaded column. Use
LND
to backspace over (erase) any characters you want to correct.
1
In software versions prior to 02.00.00, the codes for 1 + 2, 1 + 3, and 1 + 4 were not available.
