DS1000/2000 Correspondence Course
DS1000 System Installation
68 ◆ DS1000/2000 Workbook NEC America
Connecting the 2-OPX Module
80000 - 41A
BLK YEL
GRN RED
Station
Block
Cross
Connect
Block
14 AWG to known
Earth Ground
BLU-WHTWHT-BLU
625
Modular
Jack
One-Pair Cross-Connect
2-OPX Modular
DS1
FG
