Installing and Using Utilities 5-55
Procedure in NEC ESMPRO Manager
Perform the procedure below before replacement of a component.
1. Select the target component in the [ft] tree.
2. Check the current state with the "State" display on the target component screen.
3. Click the [Clear] button in the [MTBF Clear] of the target component.
The MTBF clearing result can be confirmed by the MTBF information on the target
component screen. The result of the MTBF clearing operation is reported by the server as an
alert.
CHECK:
 At this point, the "State" display on the target component screen is not changed.
 If the MTBF clear is executed in the following conditions, diagnostics of the CPU/IO
modules are automatically performed after MTBF clear:
- The target CPU/IO module is turned on
- Both of the target CPU module and IO module are stopped
4. Start the component.
CHECK:
At this point, the "State" display on the target component screen is changed.
Sample screen of NEC ESMPRO Manager
[Maintenance] screen of IO module
[PCI module] – [Maintenance]
