NEC PD78052 - General Register Configuration

603 pages

To Next Page

To Next Page

To Previous Page

To Previous Page

Loading...

113

CHAPTER 5 CPU ARCHITECTURE

BANK0

BANK1

BANK2

BANK3

FEFFH

FEF8H

FEF7H

FEE0H

HL

DE

BC

AX

H

15 0 7 0

L

D

E

B

C

A

X

16-Bit Processing 8-Bit Processing

FEF0H

FEEFH

FEE8H

FEE7H

Figure 5-22. General Register Configuration

(a) Absolute Name

(b) Function Name

BANK0

BANK1

BANK2

BANK3

FEFFH

FEF8H

FEF7H

FEE0H

RP3

RP2

RP1

RP0

R7

15 0 7 0

R6

R5

R4

R3

R2

R1

R0

16-Bit Processing 8-Bit Processing

FEF0H

FEEFH

FEE8H

FEE7H
