CHAPTER 16 SERIAL INTERFACE CHANNEL 0 ( µ PD78054 Subseries)
16.2 Serial Interface Channel 0 Configuration
Serial interface channel 0 consists of the following hardware.
Table 16-2. Serial Interface Channel 0 Configuration
Item Configuration
Serial I/O shift register 0 (SIO0)
Slave address register (SVA)
Timer clock select register 3 (TCL3)
Serial operating mode register 0 (CSIM0)
Control register Serial bus interface control register (SBIC)
Interrupt timing specify register (SINT)
Port mode register 2 (PM2)
Note
Note Refer to Figure 6-5. Block Diagram of P20, P21, P23 to P26 and Figure 6-6. Block Diagram of P22, P27.
Register
