NEC PD78052 - Logic Circuit of SCL Signal

391
CHAPTER 17 SERIAL INTERFACE CHANNEL 0 ( µ PD78054Y Subseries)
Figure 17-29. Logic Circuit of SCL Signal
Remarks 1. This figure indicates the relation of the signals and does not indicate the internal circuit.
2. CLC: Bit 3 of interrupt timing specify register (SINT)
CLC (manipulated by bit manipulation instruction)
Wait request signal
Serial clock (low while transfer is stopped)
SCL
