CHAPTER 3 PIN FUNCTION ( µ PD78054 Subseries)
Input/Output
Circuit Type
P00/INTP0/TI00 2 Input Connect to VSS.
P01/INTP1/TI01
P02/INTP2
P03/INTP3 Individually connect to V SS via a resistor.
P04/INTP4
P05/INTP5
P06/INTP6
P07/XT1 16 Input Connect to VDD.
P10/ANI0 to P17/ANI7 11
P20/SI1 8-A
P21/SO1 5-A
P22/SCK1 8-A
P23/STB 5-A
P24/BUSY 8-A
P25/SI0/SB0
P26/SO0/SB1 10-A Individually connect to VDD or VSS via a
P27/SCK0 resistor.
P30/TO0
P31/TO1 5-A
P32/TO2
P33/TI1
P34/TI2
P35/PCL
P36/BUZ 5-A
P37
P40/AD0 to P47/AD7 5-E Input/Output Individually connect to VDD via a resistor.
P50/A8 to P57/A15 5-A Input/output
Individually connect to VDD or VSS via a
resistor.
Input/Output
8-A Input/Output
Pin Name Input/Output Recommended Connection of Unused Pins
8-A
3.3 Input/output Circuits and Recommended Connection of Unused Pins
Table 3-1 shows the input/output circuit types of pins and the recommended conditions for unused pins.
Refer to Figure 3-1 for the configuration of the input/output circuit of each type.
Table 3-1. Pin Input/Output Circuit Types (1/2)
