CHAPTER 3 PIN FUNCTION (
µ
PD78054 Subseries)
3.2.8 P70 to P72 (Port 7)
This is a 3-bit input/output port. In addition to its use as an input/output port, it also has serial interface data input/
output and clock input/output functions.
The following operating modes can be specified in 1-bit units.
(1) Port mode
Port 7 functions as a 3-bit input/output port. 1-bit-units specification as an input port or output port is possible
by means of port mode register 7 (PM7). When used as input ports, on-chip pull-up resistors can be used
by defining the pull-up resistor option register L (PUOL).
(2) Control mode
Port 7 functions as serial interface data input/output and clock input/output.
(a) SI2, SO2
Serial interface serial data input/output pins
(b) SCK2
Serial interface serial clock input/output pin.
(c) RxD, TxD
Asynchronous serial interface serial data input/output pins.
(d) ASCK
Asynchronous serial interface serial clock input/output pin.
Caution When this port is used as a serial interface, the I/O and output latches must be set according
to the function the user requires.
For the setting, see the operation mode setting list in Table 19-2 “Serial Interface Channel
2”.
