CHAPTER 5 CPU ARCHITECTURE

5.4.3 Direct addressing

[Function]

This addressing directly addresses the memory indicated by the immediate data in an instruction word.

[Operand format]

Identifier Description

addr16 Label or 16-bit immediate data

[Description example]

MOV A, !0FE00H; when setting !addr16 to FE00H

Operation code 10001110 OP code

00000000 00H

11111110 FEH

[Illustration]

Memory

OP code

saddr16 (low)

saddr16 (high)
