CHAPTER 18 SERIAL INTERFACE CHANNEL 1
(b) When the automatic transmit/receive function is used by the external clock
If bit 1 (CSIM11) of serial operation mode register 1 (CSIM1) is cleared to 0, external clock operation is
set.
When the automatic transmit/receive function is used by the external clock, it must be selected so that
the interval may be longer than the values shown as follows.
Table 18-3. Interval Timing Through CPU Processing (when the external clock is operating)
CPU Processing Interval Time
When using multiplication instruction 13TCPU
When using division instruction 20TCPU
External access 1 wait mode 9TCPU
Other than above 7TCPU
Remark TCPU : 1/fCPU
fCPU : CPU clock (set by the bits 0 to 2 (PCC0 to PCC2) of the processor clock control register
(PCC) and bit 0 (MCS) of the oscillation mode selection register (OSMS))
