3.2.2 P10 to P17 (Port 1)
These are 8-bit input/output ports. Besides serving as input/output ports, they function as an A/D converter analog
input.
The following operating modes can be specified in 1-bit units.
(1) Port mode
These ports function as 8-bit input/output ports.
They can be specified in 1-bit units as input or output ports with a port mode register 1 (PM1). If used as input
ports, on-chip pull-up resistors can be used to these ports by defining the pull-up resistor option register L
(PUOL).
(2) Control mode
These ports function as A/D converter analog input pins (ANI0 to ANI7). The on-chip pull-up resistor is
automatically disabled when the pins specified for analog input.
3.2.3 P20 to P27 (Port 2)
These are 8-bit input/output ports. Besides serving as input/output ports, they function as data input/output to/
from the serial interface, clock input/output, automatic transmit/receive busy input, and strobe output functions.
The following operating modes can be specified in 1-bit units.
(1) Port mode
These ports function as 8-bit input/output ports. They can be specified in 1-bit units as input or output ports
with port mode register 2 (PM2). When they are used as input ports, on-chip pull-up resistors can be used
to them by defining the pull-up resistor option register L (PUOL).
(2) Control mode
These ports function as serial interface data input/output, clock input/output, automatic transmit/receive busy
input, and strobe output functions.
(a) SI0, SI1, SO0, SO1
Serial interface serial data input/output pins
(b) SCK0 and SCK1
Serial interface serial clock input/output pins
(c) SB0 and SB1
NEC standard serial bus interface input/output pins
