418

CHAPTER 18 SERIAL INTERFACE CHANNEL 1

Figure 18-9. Basic Transmission/Reception Mode Flowchart

ADTP : Automatic data transmit/receive address pointer

ADTI : Automatic data transmit/receive interval specify register

SIO1 : Serial I/O shift register 1

TRF : Bit 3 of automatic data transmit/receive control register (ADTC)

Start

Write transmit data

in buffer RAM

Set ADTP to the value (pointer

value) obtained by subtracting 1

from the number of transmit

data bytes

Set the transmission/reception

operation interval time in ADTI

Write any data to SIO1

(Start trigger)

Write transmit data from

buffer RAM to SIO1

Transmission/reception

operation

Write receive data from

SIO1 to buffer RAM

Pointer value = 0

TRF = 0

End

Yes

Decrement pointer value

Software Execution

Hardware Execution

Software Execution
