APPENDIX B DEVELOPMENT TOOLS
PG-1500
PROM Programmer
PA-78P054GC
PA-78P054GK
PA-78P054KK-T
PROM Programmer Adapter
A PROM programmer that, by connecting the attached board and separately
available PROM programmer adapter, is capable of programming single-
chip microcomputers incorporating a PROM on stand-alone basis or through
operation from the host machine.
Also capable of programming typical 256-Kbit to 4-Mbit PROM.
A PROM programmer adapter for the
µ PD78P054, 78P058, and 78P058Y.
Used connected to the PG-1500.
PA-78P054GC : 80-pin plastic QFP (GC-3B9, GC-8BT type)
PA-78P054GK : 80-pin plastic QFP (GK-BE9 type)
PA-78P054KK-T : 80-pin ceramic WQFN (KK-T type)
B.2 PROM Writing Tools
B.2.1 Hardware
B.2.2 Software
PG-1500 Controller Connects PG-1500 and the host machine with serial and parallel interface,
and controls the PG-1500 on the host machine.
The PG-1500 controller is a DOS-based application. Use it with the DOS
prompt on Windows.
Part number:
µ SxxxxPG1500
Remark xxxx in the part number differs depending on the host machine and OS used.
µ Sxxxx PG1500
xxxx Host Machine OS Supply Media
5A13 PC-9800 series MS-DOS 3.5-inch 2HD FD
(ver. 3.30 to ver. 6.2
Note
)
5B13 IBM PC/AT and Refer to B.4 3.5-inch 2HC FD
compatibles
Note MS-DOS ver. 5.0 or later has a task swap function, but it cannot be used with the above
software.
