APPENDIX B DEVELOPMENT TOOLS

Remark xxxx in the part number differs depending on the host machine and OS used.

Sxxxx RA78K0

Sxxxx CC78K0

Sxxxx DF78078

Sxxxx CC78K0-L

xxxx Host Machine OS Supply Media

AA13 PC-9800 series Japanese Windows

Notes 1, 2

3.5-inch 2HD FD

AB13 IBM PC/AT™ and Japanese Windows

Notes 1, 2

3.5-inch 2HC FD

BB13 compatibles English Windows

Notes 1, 2

3P16 HP9000 series 700™ HP-UX™ (rel. 9.05) DAT (DDS)

3K13 SPARCstation™ SunOS™ (rel. 4.1.4) 3.5-inch 2HC FD

3K15 1/4-inch CGMT

3R13 NEWS™ (RISC) NEWS-OS™ (rel. 6.1) 3.5-inch 2HC FD

Notes 1. Operates also in DOS environment.

2. Does not support WindowsNT™
