NEC PD78052 - External Memory Write Timing

521
CHAPTER 22 EXTERNAL DEVICE EXPANSION FUNCTION
Figure 22-6. External Memory Write Timing
(a) No wait (PW1, PW0 = 0, 0) setting
(b) Wait (PW1, PW0 = 0, 1) setting
(c) External wait (PW1, PW0 = 1, 1) setting
ASTB
WR
Higher Address
AD0-AD7
A8-A15
WAIT
Hi-Z
Lower Address
Write Data
ASTB
WR
AD0-AD7
A8-A15
Lower Address
Write Data
Higher Address
Internal Wait Signal
(1-clock wait)
Hi-Z
ASTB
WR
AD0-AD7
A8-A15
Lower Address Write Data
Hi-Z
Higher Address
