188

CHAPTER 8 16-BIT TIMER/EVENT COUNTER

PM37 PM36 PM35 PM34 PM33 PM32 PM31 PM30

76543210Symbol

PM3

FF23H FFH R/W

Address After Reset R/W

PM3n

P3n Pin Input/Output Mode Selection (n = 0 to 7)

Output mode (output buffer ON)

Input mode (output buffer OFF)

(5) Port mode register 3 (PM3)

This register sets port 3 input/output in 1-bit units.

When using the P30/TO0 pin for timer output, set PM30 and output latch of P30 to 0.

PM3 is set with a 1-bit or 8-bit memory manipulation instruction.

RESET input sets PM3 value to FFH.

Figure 8-7. Port Mode Register 3 Format
