APPENDIX B DEVELOPMENT TOOLS
An in-circuit emulator to debug hardware and software when developing
application systems that use the 78K/0 Series. Supports integrated debugger
(ID78K0). Used in combination with an interface adapter to connect to an
emulation probe and the host machine.
An adapter required for using a PC-9800 series (except notebook-type
personal computer) as the host machine for the IE-78001-R-A.
An adapter required for using an IBM PC/AT or compatible as the host
machine for the IE-78001-R-A.
An adapter and a cable required for using EWS as the host machine for the
IE-78001-R-A. Used connected to the board in the IE-78001-R-A.
Supports 10Base-5 for Ethernet
TM
. A separately available adapter required
for other systems.
A board to emulate peripheral hardware peculiar to the device. Used in
combination with an in-circuit emulator and emulation probe conversion
board.
A board required for using the IE-780308-NS-EM1 with the IE-78001-R-A
A board to emulate peripheral hardware peculiar to the device (IE-780308-R-EM
supports 2.0 to 5.0V, IE-78064-R-EM supports 3.0 to 6.0V). Used in
combination with the IE-78001-R-A.
A probe to connect an in-circuit emulator and the target system.
For 80-pin plastic QFP (GC-3B9, GC-8BT type).
A conversion socket to connect the board of a target system designed
to mount 80-pin plastic QFP (GC-3B9, GC-8BT type) and the EP-78230GC-R.
The
µ
PD78P054KK-T, 78P058KK-T, or 78P058YKK-T (ceramic WQFN)
can be mounted instead of connecting the EP-78230GC-R.
A probe to connect an in-circuit emulator and the target system.
For 80-pin plastic TQFP (GK-BE9 type).
A conversion adapter to connect the board of a target system designed to
mount 80-pin plastic TQFP (GK-BE9 type) to the EP-78054GK-R.
IE-78001-R-A
Note 1
In-circuit Emulator
IE-70000-98-IF-B or
IE-70000-98-IF-C
Note 1
Interface Adapter
IE-70000-PC-IF-B or
IE-70000-PC-IF-C
Note 1
Interface adapter
IE-78000-R-SV3
Interface Adapter
IE-780308-NS-EM1
Note 1
Emulation Board
IE-78K0-R-EX1
Note 1
Emulation Probe Conversion
Board
IE-780308-R-EM
IE-78064-R-EM
Note 2
Emulation board
EP-78230GC-R
Emulation Probe
EV-9200GC-80
Conversion Socket
(refer to Figure B-2)
EP-78054GK-R
Emulation Probe
TGK-080SDW
Conversion Adapter
(refer to Figure B-3)
B.3.1 Hardware (2/2)
(2) When using in-circuit emulator IE-78001-R-A
Notes 1. Under development
2. Maintenance product
Remarks 1. The TGK-080SDW is a product of TOKYO ELETECH Corporation.
Contact: Daimaru Kogyo Co., Ltd.
Tokyo Electronic Component Department (Tel: (03)3820-7112)
Osaka Electronic Component Department (Tel: (06)244-6672)
2. The TGK-080SDW is sold singly.
3. The EV-9200GC-80 is sold in a set of five.
