APPENDIX E REVISION HISTORY
Edition Major revisions from previous version Revised Chapters
4th The
µ
PD78052(A),78053(A), and 78054(A) were added to the Throughout
edition applicable types.
The
µ
PD78P054Y was deleted from the applicable types.
The following package was deleted from the
µ
PD78052, 78053,
78054, 78055, 78056, 78058, 78P058, 78054Y Subseries:
• 80-pin plastic QFP (14 × 14 mm, resin thickness 2.7 mm)
Figure 9-10. Square-Wave Output Operation Timing was added. CHAPTER 9 8-BIT TIMER/EVENT COUNTER
Figure 9-13. Square-Wave Output Operation Timing was added.
Note was added to Figure 16-4. Serial Operating Mode Register CHAPTER 16 SERIAL INTERFACE
0 Format. CHANNEL 0 (µPD78054 Subseries)
(4) Synchronization control and (5) Automatic transmit/receive CHAPTER 18 SERIAL INTERFACE
Interval time were added to 18.4.3 3-wire serial I/O mode CHANNEL 1
operation with automatic transmit/receive function.
Precaution was added to 19.1 (3) 3-wire serial I/O mode CHAPTER 19 SERIAL INTERFACE
(MSB-/LSB-first switchable). CHANNEL 2
Figure 19-3. Serial Operating Mode Register 2 Format was
changed.
Table 19-2. Serial Interface Channel 2 Operating Mode Settings
was changed.
Figure 19-10. Receive Error Timing was corrected.
19.4.4 Limitations when UART mode is used was added.
APPENDIX A DIFFERENCES BETWEEN
µ
PD78054, 78054Y APPENDIX A DIFFERENCES BETWEEN
SUBSERIES AND
µ
PD78058F,78058FY SUBSERIES was added. µPD78054, 78054Y SUBSERIES AND
µPD78058F,78058FY SUBSERIES
APPENDIX B DEVELOPMENT TOOL APPENDIX B DEVELOPMENT TOOL
Entire revision: Support for in-circuit emulator IE-78K0-NS
APPENDIX C EMBEDDED SOFTWARE APPENDIX C EMBEDDED SOFTWARE
Entire revision: Deletion of fuzzy inference development support
system
