CHAPTER 4 PIN FUNCTION (

PD78054Y Subseries)

5-A

Table 4-1. Pin Input/Output Circuit Types (2/2)

Input/Output

Circuit Type

P60 to P63 (Mask ROM version) 13-B Input/output Individually connect to VDD via a resistor.

P60 to P63 (PROM version) 13-D

P64/RD Input/output

Individually connect to VDD or VSS via a resistor.

P65/WR

P66/WAIT

P67/ASTB

P70/SI2/RxD 8-A

P71/SO2/TxD 5-A

P72/SCK2/ASCK 8-A

P120/RTP0 to P127/RTP7 5-A

P130/ANO0 to P131/ANO1 12-A Input/output Individually connect to VSS via a resistor.

RESET 2 Input —

XT2 16 — Leave open.

AVREF0 — Connect to VSS.

AVREF1 Connect to VDD.

AVDD

AVSS Connect to VSS.

IC (Mask ROM version) Directly connect to VSS.

VPP (PROM version)

Pin Name Input/Output Recommended Connection of Unused Pins
