ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308 Reference Manual
4-40 Firewall Protection
v1.0, April 2010
To edit a bandwidth profile:
1. In the List of Bandwidth Profiles table, click the Edit table button to the right of the bandwidth
profile that you want to edit. The Edit Bandwidth Profile screen displays.
2. Modify the settings that you wish to change (see Table 4-8 on page 4-39).
3. Click Apply to save your changes. The modified bandwidth profile is displayed in the List of
Bandwidth Profiles table.
Setting a Schedule to Block or Allow Specific Traffic
Schedules define the time frames under which firewall rules can be applied. Three schedules,
Schedule 1, Schedule 2, and Schedule3 can be defined, and you can select any one of these when
defining firewall rules.
To set a schedule:
1. Select Security > Schedule from the menu. The Schedule submenu tabs display, with the
Schedule 1 screen in view.
Figure 4-25
