ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308 Reference Manual
5-50 Virtual Private Networking Using IPsec Connections
v1.0, April 2010
9. Click Apply to save your settings. The IKE policy is added to the List of IKE Policies table.
Configuring the ProSafe VPN Client for Mode Config Operation
From a client PC running NETGEAR ProSafe VPN Client software, configure the remote VPN
client connection for Mode Config operation:
1. Right-click the VPN client icon in your Windows toolbar, and select Security Policy Editor.
Then, select Options > Secure, and verify that the Specified Connections selection is enabled
(see Figure 5-11 on page 5-12).
Extended Authentication
XAUTH Configuration
Note: For more
information about
XAUTH and its
authentication modes,
see “Configuring
XAUTH for VPN
Clients” on page 5-38.
Select one of the following radio buttons to specify whether or not Extended
Authentication (XAUTH) is enabled, and–if enabled–which device is used to
verify user account information:
• None. XAUTH is disabled. This the default setting.
• Edge Device. The VPN firewall functions as a VPN concentrator on which
one or more gateway tunnels terminate. The authentication modes that are
available for this configuration are User Database, RADIUS PAP, or RADIUS
CHAP.
• IPSec Host. The VPN firewall functions as a VPN client of the remote
gateway. In this configuration the VPN firewall is authenticated by a remote
gateway with a user name and password combination.
Authentication
Type
For an Edge Device configuration: From the drop-down list,
select one of the following authentication types:
• User Database. XAUTH occurs through the VPN
firewall’s user database. Users must be added through
the Add User screen (see “User Database Configuration”
on page 5-39).
• Radius PAP. XAUTH occurs through RADIUS Password
Authentication Protocol (PAP). The local user database is
first checked. If the user account is not present in the
local user database, the VPN firewall connects to a
RADIUS server. For more information, see “RADIUS
Client Configuration” on page 5-39.
• Radius CHAP. XAUTH occurs through RADIUS
Challenge Handshake Authentication Protocol (CHAP).
For more information, see “RADIUS Client Configuration”
on page 5-39.
Username The user name for XAUTH.
Password The password for XAUTH.
Table 5-16. Add IKE Policy Settings for a Mode Config Configuration (continued)
Item Description (or Subfield and Description)
