ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308 Reference Manual
Virtual Private Networking Using IPsec Connections 5-59
v1.0, April 2010
Configuring NetBIOS Bridging with IPsec VPN
Windows networks use the Network Basic Input/Output System (NetBIOS) for several basic
network services such as naming and neighborhood device discovery. Because VPN routers do not
normally pass NetBIOS traffic, these network services do not function for hosts on opposite ends
of a VPN connection. To solve this problem, you can configure the VPN firewall to bridge
NetBIOS traffic over the VPN tunnel.
To enable NetBIOS bridging on a configured VPN tunnel:
1. Select VPN > IPSec VPN from the menu. The IPsec VPN submenu tabs display, with the IKE
Policies screen in view (see Figure 5-20 on page 5-22).
2. Click the VPN Policies submenu tab. The VPN Policies screen displays (see Figure 5-22 on
page 5-30).
3. In the List of VPN Policies table, click the Edit table button to the right of the VPN policy that
you want to edit. The Edit VPN Policy screen displays. (Figure 5-33 shows only the top part of
the screen with the General section).
4. Select the Enable NetBIOS check box.
5. Click Apply to save your settings.
Figure 5-33
