ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308 Reference Manual
5-8 Virtual Private Networking Using IPsec Connections
v1.0, April 2010
Creating a Client to Gateway VPN Tunnel
Follow the steps in the following sections to configure a VPN client tunnel:
• “Using the VPN Wizard Configure the Gateway for a Client Tunnel” on page 5-8.
• “Using the NETGEAR VPN Client Security Policy Editor to Create a Secure Connection” on
page 5-11.
Using the VPN Wizard Configure the Gateway for a Client Tunnel
To set up a client-to-gateway VPN tunnel using the VPN Wizard:
1. Select VPN > IPSec VPN from the menu. The IPsec VPN submenu tabs display, with the IKE
Policies screen in view (see Figure 5-20 on page 5-22).
2. Click the VPN Wizard submenu tab. The VPN Wizard screen displays (see Figure 5-9 on
page 5-9, which contains some entries as an example).
Note: When using FQDNs, if the Dynamic DNS service is slow to update its servers
when your DHCP WAN address changes, the VPN tunnel will fail because the
FQDNs do not resolve to your new address. If you have the option to configure
the update interval, set it to an appropriately short time.
Figure 5-8
