ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308 Reference Manual
Connecting the VPN Firewall to the Internet 2-31
v1.0, April 2010
6. Click Apply to save your configuration.
Configuring Advanced WAN Options
The advanced options include configuration of the maximum transmission unit (MTU) size, port
speed, VPN firewall’s MAC address, and setting a rate limit on the traffic that is being forwarded
by the VPN firewall.
To configure advanced WAN options:
1. Select Network Configuration > WAN Settings from the menu.
2. Click the Edit button in the Action column of the WAN interface for which you want to
configure the advanced options. The WAN ISP Settings screen displays (see Figure 2-7 on
page 2-9, which shows the WAN1 ISP Settings screen as an example).
3. Click the Advanced option arrow at the upper right of the screen. The WAN Advanced
Options screen displays for the WAN interface that you selected (see Figure 2-21 on page
2-32, which shows the WAN1 Advanced Options screen as an example).
Note: You can also configure the failure detection method for the auto-rollover mode on
the Advanced screen. This procedure is discussed in “Configuring the Failure
Detection Method” on page 2-20.
