ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308 Reference Manual
Connecting the VPN Firewall to the Internet 2-7
v1.0, April 2010
• Down. Move down the selected entry in the table.
• Apply. Apply the selected entry.
Almost all screens and sections of screens have an accompanying help screen. To open the help
screen, click the Help icon ( ).
Configuring the Internet Connections
To set up your VPN firewall for secure Internet connections, you configure WAN ports 1
through 4. The Web Configuration Manager offers two connection configuration options:
• Automatic detection and configuration of the network connection
• Manual configuration of the network connection
Each option is detailed in a section that follows.
Automatically Detecting and Connecting
To automatically configure the WAN ports for connection to the Internet:
1. Select Network Configuration > WAN Settings from the menu. The WAN screen displays.
Figure 2-6
