ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308 Reference Manual
3-24 LAN Configuration
v1.0, April 2010
3. Click Apply to save your settings.
For information about how to define the DMZ WAN rules and LAN DMZ rules, see “Setting
DMZ WAN Rules” on page 4-14 and “Setting LAN DMZ Rules” on page 4-18, respectively.
Managing Routing
Static routes provide additional routing information to your VPN firewall. Under normal
circumstances, the VPN firewall has adequate routing information after it has been configured for
Internet access, and you do not need to configure additional static routes. You should configure
static routes only for unusual cases such as multiple firewalls or multiple IP subnets located on
your network.
DNS Proxy
Enable DNS Proxy This is optional. Select the Enable DNS Proxy radio button to enable the VPN
firewall to provide a LAN IP address for DNS address name resolution. This
setting is enabled by default.
Note: The DMZ LED next to LAN port 4 (see “Front Panel” on page 1-7) lights
green to indicate that the DMZ port is enabled.
Note: The VPN firewall automatically sets up routes between VLANs and secondary IP
addresses that you have configured on the LAN Multi-homing screen (see
“Configuring Multi-Home LAN IP Addresses on the Default VLAN” on
page 3-12). Therefore, you do not need to manually add a static route between a
VLAN and a secondary IP address.
Table 3-3. DMZ Setup Settings (continued)
Setting Description (or Subfield and Description)
