ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308 Reference Manual
9-18 Monitoring System Access and Performance
v1.0, April 2010
The active user’s user name, group, and IP address are listed in the table with a timestamp
indicating the time and date that the user logged in.
To disconnect an active user, click the Disconnect table button to the right of the user’s table entry.
Viewing the VPN Tunnel Connection Status
To view the status of current IPsec VPN tunnels:
Select VPN > Connection Status from the menu. The VPN Connection Status submenu tabs
display, with the IPSec VPN Connection Status screen in view. (Figure 9-9 shows an IPSec SA as
an example.)
The Active IPsec SAs table lists each active connection with the information that is described in
Table 9-7. The default poll interval is 5 seconds. To change the poll interval period, enter a new
value in the Poll Interval field, and then click Set Interval. To stop polling, click Stop.
Figure 9-9
Table 9-7. IPsec VPN Connection Status Information
Item Description (or Subfield and Description)
Policy Name The name of the VPN policy that is associated with this SA.
Endpoint The IP address on the remote VPN endpoint.
Tx (KB) The amount of data that is transmitted over this SA.
Tx (Packets) The number of IP packets that are transmitted over this SA.
