ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308 Reference Manual
9-16 Monitoring System Access and Performance
v1.0, April 2010
To change the poll interval period, enter a new value in the Poll Interval field, and then click Set
interval. To stop polling, click Stop.
Viewing the VLAN Status
The VLAN Status screen displays information about the VLANs (both enabled and disabled) that
are configured on the VPN firewall. For information about configuring VLAN profiles, see
“Configuring a VLAN Profile” on page 3-6. For information about enabling and disabling VLAN
profiles, see “Assigning and Managing VLAN Profiles” on page 3-3.
To view the VLAN Status screen:
1. Select Monitoring > Router Status. The Status tabs display, with the Router Status screen in
view (see Figure 9-4 on page 9-11).
2. Click the VLAN Status submenu tab. The VLAN Status screen displays.
Rx B/s The number of received bytes per second on the port.
Up TIme The period that the port has been active since it was restarted.
Figure 9-7
Table 9-5. Router Statistics Screen Fields (continued)
Setting Description (or Subfield and Description)
