ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308 Reference Manual
Firewall Protection 4-45
v1.0, April 2010
By default, the source MAC address filter is disabled. All the traffic received from PCs with any
MAC address is allowed. When the source MAC address filter is enabled, depending on the
selected policy, traffic is either permitted or blocked if it comes from any PCs or devices whose
MAC addresses are listed in MAC Addresses table.
To enable MAC filtering and add MAC addresses to be permitted or blocked:
1. Select Security > Address Filter from the menu. The Address Filter submenu tabs display,
with the Source MAC Filter screen in view (see Figure 4-27, which shows one address in the
MAC Addresses table as an example).
2. In the MAC Filtering Enable section, select the Yes radio button.
Note: For additional ways of restricting outbound traffic, see “Outbound Rules (Service
Blocking)” on page 4-4.
Figure 4-27
