ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308 Reference Manual
5-18 Virtual Private Networking Using IPsec Connections
v1.0, April 2010
• Right-click the VPN client icon in the system tray and select Log Viewer. The Log Viewer
screen displays details about the active connection or troubleshooting information that might
help you to determine why you cannot get an active connection.
The VPN client system tray icon provides a variety of status indications, which are listed below.
Figure 5-17
Table 5-7. Status Indications for the VPN Client System Tray Icon
System Tray Icon Status
The client policy is deactivated.
The client policy is deactivated but not connected.
The client policy is activated and connected.
A flashing vertical bar indicates traffic on the tunnel.
