ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308 Reference Manual
6-16 Virtual Private Networking Using SSL Connections
v1.0, April 2010
To edit a resource:
1. Select VPN > SSL VPN from the menu. The SSL VPN submenu tabs display, with the
Policies screen in view.
2. Click the Resources submenu tab. The Resources screen displays (see Figure 6-5 on page
6-15, which shows some examples).
3. In the List of Resources table, to the right of the new resource in the Action column, click the
Edit table button. A new screen displays. (Figure 6-6 shows an example.)
4. Complete the fields and make your selection from the drop-down list as explained Table 6-3.
Figure 6-6
Table 6-4.
Add Resource Addresses Settings
Item Description (or Subfield and Description)
Add Resource Addresses
Resource Name The unique identifier for the resource. For information only. (You cannot edit
the resource name after you have created it on the Resources screen.)
Service The SSL service that is assigned to the resource. For information only. (You
cannot edit the service after you have assigned it to the resource on the
Resources screen.)
