A-1
v1.0, April 2010
Appendix A
Default Settings and Technical Specifications
You can use the reset button located on the rear panel to reset all settings to their factory defaults.
This is called a hard reset (for more information, see “Reverting to Factory Default Settings” on
page 8-19).
• To perform a hard reset, press and hold the reset button for approximately 8 seconds (until the
Test LED blinks rapidly). The VPN firewall returns to the factory configuration settings that
are shown in Table A-1.
• Pressing the reset button for a shorter period of time simply causes the VPN firewall to reboot.
Table A-1 shows the default configuration settings for the VPN firewall.
Table A-1. VPN Firewall Default Configuration Settings
Feature Default Behavior
Router Login
User login URL https://192.168.1.1
Administrator user name (case-sensitive) admin
Administrator login password (case-sensitive) password
Guest user name (case-sensitive) guest
Guest login password (case-sensitive) password
Internet Connection
WAN MAC address Use default address
WAN MTU size 1500
Port speed 10/100/1000 AutoSense
Local Network (LAN)
LAN IP address 192.168.1.1
Subnet mask 255.255.255.0
RIP direction None
RIP version Disabled
