ProSafe Gigabit Quad WAN SSL VPN Firewall SRX5308 Reference Manual
Default Settings and Technical Specifications A-3
v1.0, April 2010
Table A-3 shows the IPsec VPN specifications for the VPN firewall.
Environmental Specifications
Operating temperatures
C 0º to 45º
F 32º to 113º
Storage temperatures C –20º to 70º
F –4º to 158º
Operating humidity 90% maximum relative humidity, noncondensing
Storage humidity 95% maximum relative humidity, noncondensing
Major Regulatory Compliance
Meets requirements of
FCC Class A
CE
WEEE
RoHS
Interface Specifications
4 LAN, one of which is a
configurable DMZ interface
AutoSense 10/100/1000BASE-T, RJ-45
4 WAN AutoSense 10/100/1000BASE-T, RJ-45
1 administrative console port RS-232
Table A-3. VPN Firewall IPsec VPN Specifications
Setting Specification
Network Management Web-based configuration and status monitoring
Number of concurrent users supported 125
IPsec encryption algorithm DES, 3DES, AES-128, AES-192, AES-256
IPsec authentication algorithm SHA-1, MD5
IPsec key exchange IKE, Manual Key, Pre-Shared Key, PKI, X.500
IPsec authentication types Local user database, RADIUS PAP, RADIUS CHAP
IPsec certificates supported CA digital certificate, self digital certificate
Table A-2. VPN Firewall Physical and Technical Specifications (continued)
Feature Specification
