4.15 Output to USB flash drive
FRA5087
4.15 Output to USB flash drive
The LCD screen data can be saved to USB flash drive (Windows bitmap format). Use a USB
flash drive (attached) and connect it to the USB port on the upper left of the pane.
When using the USB flash drive, please note the following.
・ Is directly inserted into the USB port (at upper left of the front panel) of the FRA5087, not
via any USB-HUB or extension cable.
・ Is not partitioned, but is constituted as one logical disk.
4.15.1 LCD screen hardcopy
Press SCREEN COPY USB MEMORY to produce a hard copy. The hard copy of the present
LCD screen is stored as an image file.
The file, which is named FRA***.BMP, is stored in the root directory of the USB flash drive.
*** can be set by [FILE NUMBER] in the range from 000 to 999. Each time the data is output
to the USB flash drive, *** increments and returns to 0 when it reaches 1000.
File size is about 150 kB.
