9.11 Impedance display function (option)
FRA5087
9-14
9.11 Impedance display function (option)
●Display items
R: Impedance or admittance
A: Resistance or conductance
B: Reactance or susceptance
●Additional graphs
Linear graphs (linear scale) and log graphs (log scale), 15 types
X axis
Y1 axis
Y2 axis
X axis
Y1 axis
Y2 axis
logF
logR
Θ
F
logR
θ
logF
A
B
F
A
B
logF
logA
logB
F
logA
logB
logF
log(-A)
logB
F
log(-A)
logB
logF
logA
log(-B)
F
logA
log(-B)
logF
log(-A)
log(-B)
F
log(-A)
log(-B)
logF
logR
---
F
logR
---
θ
logR
---
●Scale unit
Gain (abstract number)/impedance (, S)
●Voltage and current input
CH1 fixed to voltage, CH2 fixed to current
●Current shunt input conversion coefficient
0 to 1.0E+6 (resolution 5 digits or 0.01E-9), phase reverse feature
●Open/short correction feature
Open correction
Short correction
Correction formula
OFF
ON
Zx=Z-Zs
ON
OFF
Zx=Zp×Z÷(Zp-Z)
ON
ON
Zx=Zp×(Z-Zs)÷(Zp-(Z-Zs))
Zx Correction calculation result
Z Measured value (CH1/CH2)
Zs Short correction data (CH1/CH2)
Zp Open correction data (CH1/CH2)
Calculation by the aforementioned formula applies regardless of the [ANALYSIS MODE]
(analysis mode) setting.
●Maximum/minimum search feature
Search item Y1-axis maximum, Y1-axis minimum, Y2-axis maximum,
Y2-axis minimum
Search method When the function key relevant to the search item is pressed when
data marker is being displayed, the vertical axis parameters are
automatically searched and the marker moves accordingly
