4.6 Display setting
FRA5087
4-13
4.6 Display setting
Use the menu [Graph] to set parameters, states, etc. pertaining to the graph display. Since the
measurement data are stored in the internal buffer, you need not repeat the previous measurement
when changing the display format.
4.6.1 Setting display format
The FRA5087 offers two (2) display modes available to display measurement data on the screen;
one is the [SINGLE] mode where only a single graph is displayed on the screen and the other is
the [SPLIT] mode where two graphs are displayed with one in the upper part and the other in the
lower part of the screen by splitting it into two by the horizontal line in the middle of the screen.
Use the menu [Graph][WINDOW STYLE] and select either [SINGLE] or [SPLIT].
In the [SPLIT] mode, the graph surrounded by blue rim is active (rewriting is possible and the
cursor function is effective). Settings are possible for individual graphs separately for [GRID],
[DISPLAY MODE], [ANALYSIS MODE] and [PHASE RANGE].
！
CAUTION
In the following type operations, when the Screen and keys are
pressed, the graph disappears.
 The displayed data have been deleted.
The displayed data have been deleted by [MEMORY][DELETE MASS
DATA] or [MEMORY][DELETE PERMANENT DATA].
The graph remains unchanged immediately after deletion.
If you press one of the SCREEN keys after one of the following
actions has been taken, the other displayed graph will disappear.
 After the measurement in the [SINGLE] mode has been done, another set of
measurement was made by changing the mode into [SPLIT] for the first time.
In this case, the other graph is still displayed showing the previously
measured data.
 After data have been loaded from a USB flash drive in the [SINGLE] mode,
another set of measurement was made by changing the mode into [SPLIT] for
the first time. In this case, the other graph is still displayed showing the data
that have been loaded from the USB flash drive.
