6.3 File format
FRA5087
6-7
6.3.2 Format of measurement conditions files
One measurement condition file constitutes the header and the condition data. The leading
portion of the file is the header, where such information as the file size and the version number of
the FRA5087 is written in. The condition data refer to the parameters to be set for measurement
by the FRA5087.
File head
File tail
Header
Condition
data
Fig. 6-2 Structure of measurement condition file
The file formats for the header and the condition data are shown in the “Table 6-4 a) - b)
Measurement condition file format”.
Table 6-4 a) Measurement condition file format - Header
Offset
Type
Descriptions (content)
0
long
File size 4,232
4
long
(Checksum)
8
char[16]
Product type (name) “NF FRA5087 ”
24(0x18)
char[8]
File format version “3.00 ”
32(0x20)
char[8]
Type of file “CON ”
